2-Piece Set | 15mm Thick | 4x100mm | HubCentric Wheel Spacers | 57.1mm Center Bore | Chrome Extended 14x1.5 Conical Bolts | Fit Volkswagen Aftermarket Wheels

Product Specification:

About the Spacer

Spacer Type: HubCentric Wheel Spacer

Spacer Thickness: 15mm

Spacer Bolt Pattern: 4x100mm

Spacer Center Bore: 57.1mm

Spacer HubCentric Lip: Yes

Adapter Material: Cold Forged 6061 T6 Grade Aluminum

About Lug Bolts (For Aftermarket Wheels Only)

Lug Bolt Type: Conical Seat Lug Bolts

Lug Bolt Thread Pitch: M14x1.5

Lug Bolt Seat Type: Conical Seat 60 Degree

Lug Bolt Drive: 17mm Hex

Lug Bolt Shank Length: 1.77” (45mm) Extended

Lug Bolt Flange: 0.9”(23mm)

Lug Bolt Finish: Chrome

Lug Bolt Material Made: SCM Steel

Requirements of the Vehicle Specification

Required Vehicle Hub Stud Thread: M14x1.5

Required Vehicle Hub Bolt Pattern: 4x100mm

Required Vehicle Hub Center Bore: 57.1mm

Maximum Vehicle HubCentric Lip Height: 11mm

Requirements of the Wheel Specification

Required Vehicle Wheel Lug Bolts Seat Type: Conical Seat

Required Vehicle Wheel Lug Bolts Flange: 0.9” (23mm)

Required Vehicle Wheel Bolt Pattern: 4x100mm

Required Vehicle Wheel Center Bore: 57.1mm

Requirements of the Wrench Size :

Required Wrench Socket Size: 17mm Hex

What You Will Receive:

2        pcs HubCentric Wheel Spacers

8      pcs Extended Wheel Lug Bolts

Important Notes

Car Model and Year Only Determine Factory Hub Thread

Different Wheels Require Different Types of Lug Bolts

Compare Your Lug Bolts Shape Dimension Before Buying
