20-Piece Set | Black | 14x1.25 Thread | 24mm Shank | 6 Spline Tuner Locker | Performance Wheel Lug Bolts | Plus Security Socket

Product Specification:

About Lug Bolts

Lug Bolt Type: 6-Spline Tuner Lug Bolts

Lug Bolt Thread Pitch: M14x1.25

Lug Bolt Seat Type: Conical Seat 60 Degree

Lug Bolt Drive: 6-Spline 0.8” Flange

Lug Bolt Shank Length: 0.95” (24mm)

Lug Bolt Flange: 0.8”(20mm)

Lug Bolt Finish: Black

Lug Bolt Material Made: SCM Steel

About Socket Key

Socket Type: 0.8” Flange 6-Spline Tuner Lug Bolts Socket

Socket Drive: 13/16” & 3/4” Hex Drive

Socket Fit Lug Bolts: 0.8” Flange 6-Spline Tuner Lug Bolts

Socket Overall Flange: 0.85”(21mm)

Socket Overall Length: 3.55”(90mm)

Socket Material Made: SCM Steel

Max Torque Power: 100 ft-lb

Requirements of the Vehicle Specification

Required Vehicle Hub Stud Thread: M14x1.25

Requirements of the Wheel Specification

Required Vehicle Wheel Lug Bolts Seat Type: Conical Seat

Required Vehicle Wheel Lug Bolts Flange: 0.8” (20mm)

Wheel Spacers Capability : N/A

Requirements of the Wrench Size :

Required Wrench Socket Size: 0.8” Flange 6-Spline Socket

What You Will Receive:

20      pcs Wheel Lug Bolts

1       pcs Security Socket

Important Notes

Car Model and Year Only Determine Factory Hub Thread

Different Wheels Require Different Types of Lug Bolts

Compare Your Lug Bolts Shape Dimension Before Buying

For Measurement Guides, Purchase Helps, Customer Supports, Warranties, And More Details, Please Check at the Bottom Section of the Website Page.
