4-Piece Set | 10mm Thick | 5x112mm | HubCentric Wheel Spacers | 66.56mm Center Bore | Chrome Extended 12x1.5 R13 Ball Seat Bolts | Fit Mercedes Stock Wheels

Product Specification:

About the Spacer

Spacer Type: HubCentric Wheel Spacer

Spacer Thickness: 10mm

Spacer Bolt Pattern: 5x112mm

Spacer Center Bore: 66.56mm

Spacer HubCentric Lip: Yes

Adapter Material: Cold Forged 6061 T6 Grade Aluminum

About Lug Bolts (Stock Wheel Only)

Lug Bolt Type: R13 Ball Seat Lug Bolts

Lug Bolt Thread Pitch: M12x1.5

Lug Bolt Seat Type: R13 Ball Seat

Lug Bolt Drive: 17mm Hex

Lug Bolt Shank Length: 1.97” (50mm) Extended

Lug Bolt Flange: 0.9”(23mm)

Lug Bolt Finish: Chrome

Lug Bolt Material Made: SCM Steel

Requirements of the Vehicle Specification

Required Vehicle Hub Stud Thread: M12x1.5

Required Vehicle Hub Bolt Pattern: 5x112mm

Required Vehicle Hub Center Bore: 66.56mm

Required Vehicle Stock Bolts Shank Length Range: 38-42mm

Maximum Vehicle HubCentric Lip Height: 6mm

Requirements of the Wheel Specification

Required Vehicle Wheel Lug Bolts Seat Type: Ball Seat

Required Vehicle Wheel Lug Bolts Flange: 0.9” (23mm)

Required Vehicle Wheel Bolt Pattern: 5x112mm

Required Vehicle Wheel Center Bore: 66.56mm

Requirements of the Wrench Size :

Required Wrench Socket Size: 17mm Hex

What You Will Receive:

4        pcs HubCentric Wheel Spacers

20      pcs Extended Wheel Lug Bolts

Important Notes

Car Model and Year Only Determine Factory Hub Thread

Different Wheels Require Different Types of Lug Bolts

Compare Your Lug Bolts Shape Dimension Before Buying
