4-Piece Set | 5mm Thick | 4x100mm | Wheel Spacers | 57.1mm Center Bore | Chrome Extended 14x1.25 Conical Seat Bolts | Fit BMW Mini Copper 4 Lug Wheels

Product Specification:

About the Spacer

Spacer Type: HubCentric Wheel Spacer

Spacer Thickness: 5mm

Spacer Bolt Pattern: 4x100mm

Spacer Center Bore: 57.1mm

Spacer HubCentric Lip: No

Adapter Material: Cold Forged 6061 T6 Grade Aluminum

About Lug Bolts

Lug Bolt Type: Conical Seat Lug Bolts

Lug Bolt Thread Pitch: M14X1.25

Lug Bolt Seat Type: Conical Seat 60 Degree

Lug Bolt Drive: 17mm Hex

Lug Bolt Shank Length: 1.3” (33mm) Extended

Lug Bolt Flange: 0.9”(25mm)

Lug Bolt Finish: Chrome

Lug Bolt Material Made: SCM Steel

Requirements of the Vehicle Specification

Required Vehicle Hub Stud Thread: M14X1.25

Required Vehicle Hub Bolt Pattern: 4x100mm

Required Vehicle Hub Center Bore: 57.1mm

Maximum Vehicle HubCentric Lip Height: N/A

Requirements of the Wheel Specification

Required Vehicle Wheel Lug Bolts Seat Type: Conical Seat

Required Vehicle Wheel Lug Bolts Flange: 0.9” (25mm)

Required Vehicle Wheel Bolt Pattern: 4x100mm

Required Vehicle Wheel Center Bore: 57.1mm

Requirements of the Wrench Size :

Required Wrench Socket Size: 17mm Hex

What You Will Receive:

4        pcs HubCentric Wheel Spacers

16      pcs Extended Wheel Lug Bolts

Important Notes

Car Model and Year Only Determine Factory Hub Thread

Different Wheels Require Different Types of Lug Bolts

Compare Your Lug Bolts Shape Dimension Before Buying
